Radiator |
|
Radiator Dimensions |
397 x 120 x 27 mm |
Radiator Material |
Aluminum |
TDP Number |
|
Vortex360 |
280W |
Pump |
|
Dimensions |
￠67 x 48.5 mm |
Rating Voltage |
DC 12 V |
Minimum Startup Voltage |
≥ 5.0 V |
Fan Speed |
2800±10% RPM |
Rated Current |
0.25±20% A |
Consumed Power |
3.0 W |
Flow rate |
≥ 1300 mL / min |
Water Pressure |
1.4M |
Operation Temperature |
-10°C ~ +60°C |
Noise Level |
≤ 28 dB(A) |
Lifespan |
40,000 hours |
Connector |
PUMP: 3-pin | LED: 3-pin |
Fan |
|
Model Name |
Fusion 120 ARGB fan (AH12012FM1) |
Fan Type |
PWM Fan |
Dimensions |
120 x 120 x 25 mm |
Bearing Type |
Hydraulic Bearing |
LED Type |
Addressable RGB |
Fan Speed |
600±200 ~ 2000±10% RPM |
Airflow |
57.93 CFM (max.) |
Air Pressure |
2.11 mmH₂O (max.) |
Fan Noise Level |
31.24 dB(A) |
Lifespan |
40,000 hours |
Connector |
FAN: 4-pin PWM | LED: 3-pin |
Rated Voltage |
FAN: DC 12 V | LED: DC 5 V |
Operation Voltage |
FAN: DC 6.0-13.8 V | LED: DC 4.5-5.5 V |
Rated Current |
FAN : ≤ 0.21 A | LED : ≤ 0.58 A |
Socket Compatibility CPU |
Intel : LGA 115X / 1200 / 1700 / 20XX |
AMD : AM3/AM4/AM5 |
|
