Picture/Display
|
Panel Size
|
23.8 inch / 60.5 cm
|
Aspect ratio
|
16:09
|
LCD panel type
|
IPS technology
|
Backlight type
|
W-LED system
|
Pixel pitch
|
0.2745 x 0.2745 mm
|
Brightness
|
300 cd/m²
|
Display colors
|
16.7 M (8 bits)
|
Color gamut (typical)
|
Adobe RGB 88%, DCI-P3:93%, sRGB: 126%, NTSC 113%*
|
Contrast ratio (typical)
|
1000:1
|
SmartContrast
|
Mega Infinity DCR
|
Response time (typical)
|
1 ms (Gray to Gray)*
|
Viewing angle
|
178º (H) / 178º (V)
@ C/R > 10
|
Picture enhancement
|
SmartImage game
|
Maximum resolution
|
1920×1080 @ 180 Hz
|
Effective viewing area
|
527.04 (H) x 296.46 (V)
|
Scanning Frequency
|
30k – 200 kHz (H) / 48 – 180 Hz (V)
|
sRGB
|
Yes
|
Flicker-free
|
Yes
|
Pixel Density
|
93 PPI
|
LowBlue Mode
|
Yes
|
Display Screen Coating
|
Anti-Glare, 3H, Haze 25%
|
EasyRead
|
Yes
|
HDR
|
HDR 10 supported
|
Smart Crosshair
|
Yes
|
Shadow Boost
|
Yed
|
Smart MBR
|
0.5ms*
|
Connectivity
|
Signal Input
|
HDMI 2.0 x 2, DisplayPort 1.4 x 1
|
Sync Input
|
Separate Sync
|
Audio (In/Out)
|
Audio out
|
HDCP
|
HDCP 1.4 (HDMI / DP), HDCP 2.2 (HDMI / DP)
|
Convenience
|
Built-in Speakers
|
2W x 2
|
Plug & Play Compatibility
|
DDC/CI
Mac OS X
sRGB
Windows 11 / 10
|
User convenience
|
Power On/Off
Menu/OK
Input/Up
Game Settings/Down
SmartImage game/Back
|
Other convenience
|
Kensington lock
VESA mount (100x100mm)
LowBlue Mode
|
Stand
|
Tilt
|
-5/20 degree
|
Power
|
Power supply
|
Internal
100-240VAC, 50-60Hz
|
Off mode
|
0.3 W (typ.)
|
On mode
|
18.7 W (typ.)
|
Standby mode
|
0.5 W (typ.)
|
Power LED indicator
|
Operation – White
Standby mode- White (blinking)
|
Dimensions
|
Packaging in mm (WxHxD)
|
610 x 395 x 126 mm
|
Product without stand (mm)
|
540 x 325 x 55 mm
|
Product with stand(max height)
|
540 x 433 x 195 mm
|
Weight
|
Product with packaging (kg)
|
5.51 kg
|
Product with stand (kg)
|
3.38 kg
|
Product without stand (kg)
|
2.77 kg
|
Operating conditions
|
Altitude
|
Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)
|
Temperature range (operation)
|
0°C to 40 °C
|
MTBF
|
50,000 (Excluded backlight) hour(s)
|
Relative humidity
|
20%-80 %
|
Temperature range (storage)
|
-20°C to 60 °C
|
Sustainability
|
Environmental and energy
|
RoHS
|
Recyclable packaging material
|
100 %
|
Specific Substances
|
Mercury free
PVC / BFR free housing
|
Post consumer recycled plastics
|
85%*
|
Cabinet
|
Color
|
Charcoal
|
Finish
|
Textured
|
