PERFORMANCE

Processor

Intel® Core™ i7-1255U, 10C (2P + 8E) / 12T, P-core 1.7 / 4.7GHz, E-core 1.2 / 3.5GHz, 12MB

Graphics

NVIDIA® GeForce MX550 2GB GDDR6

Chipset

Intel® SoC Platform

Memory

16GB Soldered DDR4-3200

Memory Slots

Memory soldered to systemboard, no slots, dual-channel (Intel® i5 / i7 models)

Max Memory

16GB soldered memory, not upgradable

Storage

512GB SSD M.2 2242 PCIe® 4.0×4 NVMe®

Storage Support

Models with 76Wh battery: one drive, 1x M.2 SSD • M.2 2242 SSD up to 512GB • M.2 2280 SSD up to 1TB

Storage Slot

Models with 76Wh battery: one M.2 slot • One M.2 2280 PCIe® 4.0 x4 slot

Card Reader

SD Card Reader

Optical

None

Audio Chip

High Definition (HD) Audio, Realtek® ALC3287 codec

Speakers

Stereo speakers, 2W x2, optimized with Dolby Audio™

Camera

FHD 1080p with Privacy Shutter

Microphone

2x, Array

Battery

Integrated 76Wh

Power Adapter

65W USB-C® (3-pin)

DESIGN

Display

15.6″ FHD (1920×1080) IPS 300nits Anti-glare, 45% NTSC

Touchscreen

None

Keyboard

Backlit, Arabic

Case Color

Storm Grey

Surface Treatment

Aluminium Stamping (Anodized)

Case Material

Aluminium (Top), PC-ABS (Bottom)

Dimensions (WxDxH)

356.67 x 233.13 x 17.9 mm (14.04 x 9.18 x 0.70 inches)

Weight

Starting at 1.77 kg (3.90 lbs)

SOFTWARE

Operating System

None

Bundled Software

None

CONNECTIVITY

Ethernet

No Onboard Ethernet

WLAN + Bluetooth

Wi-Fi® 6, 11ax 2×2 + BT5.2

Standard Ports

• 1x USB 3.2 Gen 1

• 1x USB 3.2 Gen 1 (Always On)

• 2x USB-C® 3.2 Gen 1 (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.2)

• 1x HDMI® 1.4b

• 1x Headphone / microphone combo jack (3.5mm)

• 1x SD card reader

Docking

Various docking solutions are supported via USB-C®. For more compatible docking solutions, please visit Docking for IdeaPad® 5 15IAL7

SECURITY & PRIVACY

Security Chip

Firmware TPM 2.0

Fingerprint Reader

Touch Style, Integrated in Power Button

Other Security

Camera privacy shutter

SERVICE

Base Warranty

1-year, Courier or Carry-in

Included Upgrade

None

ACCESSORIES

Bundled Accessories

None

CERTIFICATIONS

Green Certifications

• ErP Lot 3

• RoHS compliant

Mil-Spec Test

MIL-STD-810H military test passed
