CPU

LGA1700 socket: Support for 13th Generation Intel® Core™ Processors and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors*

L3 cache varies with CPU

Chipset

Intel^® H610 Express Chipset

Memory

1.Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s memory modules

2. 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory

3. Dual channel memory architecture

4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)

5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

6. Support for Extreme Memory Profile (XMP) memory modules

Onboard Graphics

Integrated Graphics Processor-Intel® HD Graphics support:

1. 1 x D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz

1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz

Audio

1. Realtek® Audio CODEC

2. High Definition Audio

3. 2/4/5.1/7.1-channel

Expansion Slots

CPU:

1. 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16

Chipset:

2. 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1

Storage Interface

Chipset:

1. 1 x M.2 connector (Socket 3, M key, type 2280/2260 PCIe 3.0 x4/x2 SSD support)

2. 4 x SATA 6Gb/s connectors

USB

Chipset:

1. 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)

2. 4 x USB 2.0/1.1 ports on the back panel

Chipset+USB 2.0 Hub:

3. 4 x USB 2.0/1.1 ports available through the internal USB headers

Internal I/O Connectors

1. 1 x 24-pin ATX main power connector

2. 1 x 8-pin ATX 12V power connector

3. 1 x CPU fan header

4. 2 x system fan headers

5. 1 x M.2 Socket 3 connector

6. 4 x SATA 6Gb/s connectors

7. 1 x RGB LED strip header

8. 1 x front panel header

9. 1 x front panel audio header

10. 1 x USB 3.2 Gen 1 header

11. 2 x USB 2.0/1.1 headers

12. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)

13. 1 x serial port header

14. 1 x Clear CMOS jumper

Back Panel Connectors

1. 1 x PS/2 keyboard port

2. 1 x PS/2 mouse port

3. 1 x D-Sub port

4. 1 x HDMI port

5. 2 x USB 3.2 Gen 1 ports

6. 4 x USB 2.0/1.1 ports

7. 1 x RJ-45 port

8. 3 x audio jacks

I/O Controller

iTE^® I/O Controller Chip

H/W Monitoring

1.  Voltage detection

2. Temperature detection

3. Fan speed detection

4. Water cooling flow rate detection

5. Fan fail warning

6. Fan speed control

BIOS

1. 1 x 128 Mbit flash

2. Use of licensed AMI UEFI BIOS

3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI  5.0

Form Factor

Micro ATX Form Factor; 23.0cm x 21.5cm
