Picture/Display

LCD panel type

IPS technology

Backlight type

W-LED system

Panel Size

23.8 inch/60.5 cm

Display Screen Coating

Anti-Glare, 3H, Haze 25%

Effective viewing area

527.04 (H) x 296.46 (V)

Aspect ratio

16:09

Maximum resolution

1920 x 1080 @ 165 Hz*

Pixel Density

92.56 PPI

Response time (typical)

4 ms (Grey to Grey)*

MPRT

1 ms

Low Input Lag

Yes

Brightness

250  cd/m²

SmartContrast

Mega Infinity DCR

Contrast ratio (typical)

1100:01:00

Pixel pitch

0.2745 x 0.2745 mm

Viewing angle

178º (H)/178º (V)

@ C/R > 10

Flicker-free

Yes

Colour gamut (min.)

DCI-P3 94.1%*

Colour gamut (typical)

NTSC 80.5%*, sRGB 99.9%*, Adobe RGB 90.4%*

Picture enhancement

SmartImage game

Display colours

16.7 M

Scanning Frequency

30 – 200 kHz (H) / 48 – 165 Hz (V)

LowBlue Mode

Yes

EasyRead

Yes

sRGB

Yes

AMD FreeSync™ technology

Premium

Connectivity

Signal Input

HDMI x 2, DisplayPort x 1

HDCP

HDCP 2.2 (HDMI/DisplayPort)

Audio (In/Out)

Audio out

Sync Input

Separate Sync

Convenience

User convenience

Power On/Off

Menu/OK

Input/Up

Game Settings/Down

SmartImage game/Back

Other convenience

Kensington lock

VESA mount (100 x 100 mm)

Plug and Play Compatibility

DDC/CI

Mac OS X

sRGB

Windows 10 / 8.1 / 8 / 7

Stand

Height adjustment

130  mm

Pivot

-/+ 90 degree

Swivel

-/+ 45  degree

Tilt

-5/20  degree

Power

On mode

24 W (typ.)

Standby mode

0.5 W (typ.)

Off mode

0.3 W (typ.)

Power LED indicator

Operation – White

Standby mode – White (flashing)

Power supply

External

100–240 VAC, 50–60 Hz

Dimensions

Product with stand (max height)

540 x 513 x 213  mm

Product without stand (mm)

540 x 321 x 43  mm

Packaging in mm (W x H x D)

600 x 526 x 164  mm

Weight

Product with stand (kg)

3.70  kg

Product without stand (kg)

2.40  kg

Product with packaging (kg)

5.65  kg

Operating conditions

Temperature range (operation)

0°C to 40  °C

Temperature range (storage)

-20°C to 60  °C

Relative humidity

20%-80  %

Altitude

Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m)

MTBF

50 000 (Excluded backlight)  hour(s)

Sustainability

Environmental and energy

RoHS

Recyclable packaging material

100  %

Specific Substances

Mercury free

PVC/BFR free housing

Compliance and standards

Regulatory Approvals

CB

CE Mark

FCC Class B

ICES-003

Cabinet

Colour

Black

Finish

Textured
